Accessories / Parts

Sciencetech's [130-REC] is a cooling water recirculator. It is designed to work with any of Sciencetech's liquid cooled solar cell chucks. This recirculator can maintain your sample at room temperature while sinking up to 500W of power from your light source.

-Dissipates up to 500W of thermal heat
-External fan cooled radiator system
-Cools to ambient temperature
-Real time sample temperature display (in °C or °F)
-Adjustable cooling rate

$ 1,716.00

Sciencetech's [160-REC] is a cooling water recirculator. It is designed to work with any of Sciencetech's liquid cooled solar cell chucks. This recirculator can maintain your sample at room temperature while sinking up to 900W of power from your light source.

-Dissipates up to 900W of thermal heat
-External fan cooled radiator system
-Cools to ambient temperature
-Real time sample temperature display (in °C or °F)
-Adjustable cooling rate

$ 2,016.00

This is a housing designed for Sciencetech's 188-8060 IR Sources. It includes an Elliptical reflector for focusing the output IR light to a point. The reflector is an F/4.5 reflector, Sciencetech part # 620-0205.

For the Parabolic reflector option, please see part number 100-9071.

$ 2,250.00

This is a housing designed for Sciencetech's 188-8060 IR Sources. It includes a Gold Coated parabolic reflector.

For the Elliptical reflector option, please see part number 100-9074

$ 2,250.00

Sciencetech's Model [200-REC] is a Cooling Water Recirculator. It is designed to work with any of Sciencetech's Cooled PMT Housings and can sink up 400W of heat from the Thermoelectric cooling element.

-Dissipates up to 400W of thermal heat
-External fan cooled radiator system
-Cools to ambient temperature
-Real time sample temperature display (in °C or °F)
-Adjustable cooling rate

$ 555.00

Sciencetech's Model [210-REC] is a Cooling Water Recirculator. It sink up to 2500W of heat.

-Dissipates up to 2500W of thermal heat
-External fan cooled radiator system
-Cools to ambient temperature
-Real time sample temperature display (in °C or °F)
-Adjustable cooling rate

Contact for Pricing

Spectralon Reflective Coating Standard,( Zenith White and Gold Coating available)
1.5" diameter entrance/exit port (1), 1" diameter application ports (3) (90 degree, North Pole and 180 degree)
Additional Ports and reduction of ports possible
Internal baffle on 90 deg port

$ 3,681.00

Sciencetech 500-110-QTH is an external fixed power supply for QTH lamps. Being a linear power supply as opposed to a switching power supply, it produces a highly stabilized 12VDC noise free output. This supply works with 12VDC lamps up to 100W total power. The unit accepts both 110-120VAC and 220-240VAC inputs.

$ 1,355.00

The Sciencetech 500-1K is a variable DC power supply for Xenon (Xe) and Mercury Xenon (Hg-Xe) arc lamps from 500 W to 1kW. It can drive lamps with a voltage of up to 25V and currents up to 50A. This power supply can be used with an internal or external igniter (not included). This power supply is compatible with FS-02 optical feedback unit.
This power supply is compatible with Sciencetech models 200-1K and 201-1K arc lamp housings.

Digital display: power in watts, current in amps, voltage in volts
Manual current adjustment
Operates as a constant current source

As the current setting is adjustable, the actual value of power, voltage or current of the lamp is shown on a LCD digital display.
Input Voltage Requirements
Please note that this power supply requires 100-240VAC input voltage with line current 12A from input voltage 115V line or line current 6A from 240V line.
Preliminary Specifications
Input Voltage: 100VAC-240VAC
Power: 500W-1KW
Output Current: 10A-50A

Boost Voltage: 250V
Boost Energy: 10 Joules
Ignition Voltage: >30KV (~1usec rise time)
Ignition Energy: 0.5 Joules

Lamp Connectors: PS50GR/PS50GB Superior Electric Supercon

Line Regulation: <0.02% of maximum output current
Current Regulation: <0.5% of maximum output current
Current Ripple: <0.5% of maximum output current
Power Limit: Limited to maximum power with power fold-back circuit
Power factor correction: >98%
Overall efficiency: >80%
Input line frequency range: 47-63Hz

Operating Temp: 0 to 40
Storage: -25 to 85
Humidity: 0 to 95% non-condensing

Cooling: Forced air with internal fans

Weight: 6kg
Size: 5.5” (H) x 13” x 17”
Rack mountable standard

$ 4,875.00

An adjustable power supply for Sciencetech's line of 1kW Mercury (Hg) Lamps.

$ 6,804.00

Sciencetech's 500-1K-QTH is an external 1,000W fixed power supply for QTH lamps. Sciencetech's 1000W QTH power supply produces a highly stabilized 120VDC low noise output and can output upto 10A. The current output to the lamp is not adjustable with this power supply. If you require an adjustable power supply for a Sciencetech Incandescent source see the 612-2K power supply.
This power supply is designed to work with Sciencetech XLH lamp houses with QTH or other resistive element type lamps having maximum voltage of 120VDC. The power supply will operate resistive element type lamps at their nominal operating voltage and current. This will result in the lamp emitting a spectra at it's nominal colour temperature.

The 500-1K-QTH unit accepts both 110-120VAC and 220-240VAC inputs.

$ 4,513.00

This is an adjustable power supply for Sciencetech's line of 500W Mercury (Hg) Lamps.

$ 3,959.00

This power supply has been specifically designed for the highly stable 75W Hg lamp used inside the new SPS-300 Terahertz FTIR Spectrometer. The '500-75ST' is an adjustable, current regulated, DC Power Supply. It is meant to power up a low pressure, long arc Hg lamp by Heraeus Nobelight Model 75ST. However, it can be used by many other applications which require a steady, low noise current regulated Power Supply of up to 1A, and approximately 100W. It will work with the 500-IG-75ST 800V igniter (150-9016) to ignite the Hereaus 75ST lamp. Please do not use this power supply connected to a UPS stabilizer.


LCD Display (Current, Voltage, Power)
Output Current Control: 0-1A
Dual line voltage: 115 / 230VAC
Input Current: 1A / 0.5A
Input Frequency: 60Hz / 50Hz
Dimensions (L x W x H): 11" x 8" x 5" (28cm x 20cm x 13cm)
Weight: 10 kg (22 lbs)

$ 4,250.00

Replacement igniter for the obsolete 500-IG igniter. The 500-IG igniter was used with Sciencetech 550-200 power supplies.
The 500-AS replacement igniter connects to the 550-200 power supply with the standard 3-pin cable used by the 500-IG igniter. The different ready voltage technology used by this igniter requires a second connection using the standard Sciencetech 4-pin interlock cable (included). The igniter connects to Sciencetech 200F-100 and 201C-100 type lamphouses using the same banana jacks and a second 4-pin interlock cable.

$ 925.00

This power supply is designed for use with Sciencetech's line of IR sources (including, but not limited to, the Globar, and several of our infrared emitter coils). If you are uncertain if this is the correct power supply for your system, please speak with your authorized Sciencetech technical sales staff member.

$ 940.00

The 500-IG-75ST model igniter is used to ignite the ST-75 Hg arc lamp. The igniter produces a conditioned 800V ignition pulse to the lamp. This igniter should be used in conjunction with the 75W Fixed power supply (150-9041) and the ST75 light source (100-9070)

$ 561.00

Sciencetech's touchscreen 75W xenon arc lamp power supply designed for use with Sciencetech's LH- series lamp housing.
This power supply features a 7W2 connection so that only one cable is required to supply all lamp power and communication to the lamp housing. This power supply also has a shutter connection and RS232 connection for electronic control of a shutter or computer control of the power supply if those optional accessories are purchased.

601 series power supplies accept 110-240VAC input. Includes a USB to serial adapter.
This system includes 1 IEC 60320 C13 compatible power cable. Region-specific version must be selected at the time of placing an order (see product 491-9001).

Features
-single 7W2 connection for lamp power, cooling, and communication to lamp house
-easy-to-use touchscreen interface
-shutter and exposure control (if electronic shutter upgrade is ordered)
-lamp start and time log
-safety interlocks

Optional Upgrades
-RS232 computer control with GUI
-temperature monitor
-remote lamp status monitoring
-auto lamp starting

$ 2,767.00

Sciencetech's touchscreen 100W xenon arc lamp power supply designed for use with Sciencetech's LH- series lamp housing.
This power supply features a 7W2 connection so that only one cable is required to supply all lamp power and communication to the lamp housing. This power supply also has a shutter connection and RS232 connection for electronic control of a shutter or computer control of the power supply if those optional accessories are purchased.

601 series power supplies accept 110-240VAC input.
This system includes 1 IEC 60320 C13 compatible power cable. Region-specific version must be selected at the time of placing an order (see product 491-9001).
Includes a USB to serial adapter.

Features
-single 7W2 connection for lamp power, cooling, and communication to lamp house
-easy-to-use touchscreen interface
-shutter and exposure control (if electronic shutter upgrade is ordered)
-lamp start and time log
-safety interlocks

Optional Upgrades
-RS232 computer control with GUI
-temperature monitor
-remote lamp status monitoring
-auto lamp starting

$ 2,767.00

Sciencetech's touchscreen 150W xenon arc lamp power supply designed for use with Sciencetech's LH- series lamp housing.
This power supply features a 7W2 connection so that only one cable is required to supply all lamp power and communication to the lamp housing. This power supply also has a shutter connection and RS232 connection for electronic control of a shutter or computer control of the power supply if those optional accessories are purchased.

601 series power supplies accept 110-240VAC input.
This system includes 1 IEC 60320 C13 compatible power cable. Region-specific version must be selected at the time of placing an order (see product 491-9001).
Includes a USB to serial adapter.

Features
-single 7W2 connection for lamp power, cooling, and communication to lamp house
-easy-to-use touchscreen interface
-shutter and exposure control (if electronic shutter upgrade is ordered)
-lamp start and time log
-safety interlocks

Optional Upgrades
-RS232 computer control with GUI
-temperature monitor
-remote lamp status monitoring
-auto lamp starting

$ 3,460.00

Sciencetech's touchscreen 300W xenon arc lamp power supply designed for use with Sciencetech's LH- series lamp housing.
This power supply features a 7W2 connection so that only one cable is required to supply all lamp power and communication to the lamp housing. This power supply also has a shutter connection and RS232 connection for electronic control of a shutter or computer control of the power supply if those optional accessories are purchased.

601 series power supplies accept 110-240VAC input.

This system includes 1 IEC 60320 C13 compatible power cable. Region-specific version must be selected at the time of placing an order (see product 491-9001).

Includes a USB to serial adapter.

Features
-single 7W2 connection for lamp power, cooling, and communication to lamp house
-easy-to-use touchscreen interface
-shutter and exposure control (if electronic shutter upgrade is ordered)
-lamp start and time log
-safety interlocks
-RS232 software GUI included, shown below

Optional Upgrades
-temperature monitor
-remote lamp status monitoring
-auto lamp starting

$ 3,460.00
