    Gratings

    Grating Selection

    Diffraction gratings are surfaces with a periodic structure used to diffract broad spectrum light at different angles according to wavelength, allowing the component wavelengths

    Grating selection is a crucial part of building a monochromator. Each ruled or holographic grating is designed to diffract light most efficiently over a specific band of wavelengths.

    This tool allows you to compare efficiency curves for different gratings that Sciencetech offers. These curves are for comparison purposes only [1].

    Currently Comparing:

    • Use the filters and table below to select gratings and add them to the chart.

    Filter:

    Type

    Nominal Blaze (nm)

    Groove Density (l/mm)

    Size (mm)

    82 gratings matching your criteria

    SKU Type Size (mm) Blaze (nm) Groove (l/mm) Compare
    630-0087 Plane Ruled 30×30 400 1200
