Rotating blade chopper
2 opening blade for frequency range of 4-200Hz.
Higher frequency ranges available with other blades.
Includes enclosure and driver
1-D slip ring with H4 hole pattern on input face, 2-D slip ring with S4 hole pattern on output face for integration with Sciencetech modular instruments.
** Warning ** This chopper accepts a maximum 1" diameter collimated beam at the chopper port. For 1" diameter collimated beams the CH-MC-E-1D1D chopper is usually used.
The CH-MC-E-1D2D chopper is usually used in cases where a convergent beam enters the chopper housing from a 2" optical tube.
This chopper is compatible with SciSpec and SciPV software. For integration into Sciencetech instruments or larger integrated systems see SciencetechCOM and SciAX software.
Third party control software is included with this chopper but is not supported by Sciencetech.
