Gratings

Grating Selection

Diffraction gratings are surfaces with a periodic structure used to diffract broad spectrum light at different angles according to wavelength, allowing the component wavelengths

Grating selection is a crucial part of building a monochromator. Each ruled or holographic grating is designed to diffract light most efficiently over a specific band of wavelengths.

This tool allows you to compare efficiency curves for different gratings that Sciencetech offers. These curves are for comparison purposes only [1].

Currently Comparing:

  • Use the filters and table below to select gratings and add them to the chart.

Filter:

Type

Nominal Blaze (nm)

Groove Density (l/mm)

Size (mm)

82 gratings matching your criteria

SKU Type Size (mm) Blaze (nm) Groove (l/mm) Compare
631-0001 Plane Holographic 50×50 250 1200
631-0002 Plane Ruled 50×50 240 1800
631-0003 Plane Holographic 50×50 500 1800
631-0005 Plane Holographic 50×50 250 2400
631-0010 Plane Ruled 50×50 400 1200
631-0011 Plane Ruled 50×50 300 1200
631-0012 Plane Ruled 50×50 2000 300
631-0013 Plane Ruled 50×50 500 300
631-0014 Plane Ruled 50×50 750 600
631-0019 Plane Ruled 50×50 750 1200
631-0020 Plane Ruled 50×50 1600 600
631-0021 Plane Ruled 50×50 500 1800
631-0024 Plane Ruled 50×50 1000 1200
638-0025 Plane Ruled 50×50 1000 600
631-0027 Plane Holographic 50×50 250 1200
631-0028 Plane Ruled 50×50 1250 600
631-0032 Plane Ruled 50×50 500 600
638-0033 Plane Ruled 50×50 250 1200
631-0037 Plane Ruled 50×50 500 1200
638-0040 Plane Ruled 50×50 400 600
638-0041 Plane Ruled 50×50 2000 300
631-0051 Plane Ruled 50×50 1200 830
631-0055 Plane Ruled 50×50 500 150
631-0056 Plane Ruled 50×50 1000 300
631-0057 Plane Ruled 50×50 4000 300
631-0058 Plane Ruled 50×50 12000 120
631-0062 Plane Ruled 50×50 1000 600
631-0070 Plane Ruled 50×50 800 830
631-0075 Plane Ruled 50×50 250 1200
631-0080 Plane Holographic 50×50 500 1200
638-0082 Plane Ruled 50×50 150 1200

[1] Only average curves are shown; for efficiency with regard to S and P polarization, please contact us.

These efficiency curves are measured in Littrow configuration. Our monochromators use different configurations, and so have some limitations in geometry that limit the wavelength range. Please contact us to verify that your chosen grating is compatible with your selected monochromator model at the desired wavelength.
